The difference between induction furnace and electric arc furnace

Induction furnaces and electric arc furnaces are both used for melting metals, but they operate based on different principles and are used for different applications.

Operating Principle

Induction Furnace

Induction furnaces use electromagnetic induction to heat and melt the metal. An alternating current (AC) passes through a coil, creating a magnetic field. This magnetic field induces eddy currents in the metal charge, generating heat and causing it to melt.

Electric Arc Furnace (EAF)

Electric arc furnaces use an electric arc to generate heat. An electric current passes through electrodes, creating an arc between the electrodes and the metal charge. The intense heat from the arc melts the metal.

Equipment structure

Induction Furnace

The furnace consists of a coil made of copper tubing through which a high-frequency current flows, creating a magnetic field. The metal to be melted is placed inside a crucible within the coil.

Electric Arc Furnace (EAF)

The furnace consists of a refractory-lined vessel with graphite electrodes that can be raised or lowered to create the arc. The metal charge is placed in the hearth of the furnace.


Induction Furnace

Induction furnaces are ideal for melting metals and alloys that require precise temperature control and minimal contamination, such as in the production of high-quality steel, aluminum, and precious metals.

They are typically used for small to medium-scale operations due to their relatively lower melting capacity compared to electric arc furnaces.

Electric Arc Furnace (EAF)

Electric arc furnaces are used for large-scale melting operations, such as in steelmaking, where scrap metal is melted to produce new steel. Due to the characteristics of electric arc furnaces melting metal at high temperatures, they are widely used and can melt a variety of metal materials such as high iron alloys, alloy steels, cast steel, manganese alloys, silicon, etc.

Heating efficiency

Induction Furnace

Using Joule heating, heat is generated within the metal itself due to the eddy current resistance caused by the magnetic field. This results in very uniform heating and high energy efficiency. The heating speed is fast, the production efficiency is high, the oxidation decarbonization is less, and the material is saved.

Electric Arc Furnace (EAF)

Although the heating efficiency of electric arc furnaces is generally lower than that of induction furnaces, electric arc furnaces can process large quantities of scrap metal and have the flexibility to process different types of alloys. Due to the intense heat of the arc, the melting rate is high, making them suitable for industrial-scale operations.

Energy consumption

Induction Furnace

Since the principle of induction heating is electromagnetic induction, the heat is generated within the workpiece itself, which has lower energy consumption.

Electric Arc Furnace (EAF)

With the development of the electric power industry, the continuous improvement of process equipment and the improvement of smelting technology, the electric energy consumption of electric arc furnaces has gradually decreased, but its overall energy consumption level may vary depending on the specific process and equipment.

Summary of Key Differences

FeatureInduction FurnaceElectric Arc Furnace
Heat SourceElectromagnetic induction (eddy currents)Electric arc
ElectrodesNot usedGraphite electrodes used to create the arc
Heating EfficiencyHigh (due to direct heating of metal)Lower compared to induction furnaces
Melting CapacitySmall to medium scaleLarge scale
ApplicationsPrecision melting, high-quality alloys, small batchesLarge scale melting, steel production, recycling
ContaminationLow (can be performed in a controlled atmosphere)Higher (exposure to atmosphere, but can be mitigated)
ControlPrecise temperature controlGood control but less precise than induction furnaces
Energy ConsumptionGenerally lowerHigher, but can be offset by using cheaper scrap materials

In summary, there are significant differences between induction furnaces and electric arc furnaces in terms of working principles, equipment structure, scope of application, heating efficiency and flexibility, energy consumption, and environmental protection. Which furnace type to choose depends on specific production needs, material properties, and environmental requirements.
